Hot dipped galvanized pipe
Hot dipped galvanized pipe owns thicker zinc coating than pre-galvanized pipe, black pipes will be dipped into zinc pool for galvanized.
Zinc coating: 275 – 600g /m2
| Place of Origin: 原产地： | Tianjin, China 中国天津 |
| Brand Name: 品牌名称: | Teni |
| Model Number: 型号: | |
| Certification: 认证: | ISO, BV, SGS, CE |
| Minimum Order Quantity: 起订数量： | 5 TONS 5吨 |
| Price: 价格: | FOB 530-620 USD/TON 离岸价530-620美元/吨 |
| Packaging Details: 包装细节: | 1water-proof plastic cloth, |
| Delivery Time: 交货时间: | 1.Usually,within10-20days after we received your advance payment. 2.According to the order quantity1.通常，在我们收到你方预付款后10-20天内。根据订单数量 |
| Payment Terms: 付款条件: | T/T, L/C 电汇,信用证 |
| End Treatment: 结束治疗 | 1.Plain ends, 2.Socket/coupling and Threading, 3.Plastic caps, 4.Beveled ends, and so on1.普通的结束,2。套接字/耦合和线程；4.塑料瓶盖；斜面末端，等等 |
Standard 标准
GB/T3091 – 2001, BS1387 – 1985, DIN EN10025, EN10219, JIS G3444: 2004, ASTM A53
Steel Grade 钢的等级
GB/T3091 – 2001: Q195, Q235, Q345Gb / t3091 - 2001: q195、q235、q345
BS1387 – 1985, DIN EN10025, EN10219: S235JR, S275JR, S355JR, S355J2H
JIS G3444: 2004: STK400, STK500
ASTM A53: GR. A, GR. B, GR. C, GR. D
Usage: Used for low pressure liquid delivery, such as water, gas, and oil, fence, conduit, green house etc.
| Outer Diameter | Wall Thickness | Length | |
| Inch | mm | mm | meter |
| 1/2" | 21.3mm | 0.6mm-3.0mm | 0.3m-12m |
| 3/4" | 26.9mm | 0.6mm-3.0mm | 0.3m-12m |
| 1" | 33.4mm | 1.0mm-3.0mm | 0.3m-12m |
| 1-1/4" | 42.3mm | 1.0mm-4.0mm | 0.3m-12m |
| 1-1/2" | 48.3mm | 1.0mm-4.0mm | 0.3m-12m |
| 2" | 60.3mm | 1.5mm-4.0mm | 0.3m-12m |
| 2-1/2" | 76.1mm | 1.5mm-4.0mm | 0.3m-12m |
| 3" | 88.9mm | 1.5mm-9.5mm | 0.3m-12m |
| 4" | 114.3mm | 2.0mm-9.5mm | 0.3m-12m |
| 5" | 141.3mm | 3.0mm-9.5mm | 0.3m-12m |
| 6" | 168.3mm | 3.0mm-12.0mm | 1.0m-12m |
| 8" | 219.1mm | 3.2mm-12.0mm | 1.0m-12m |
| 10" | 273mm | 3.2mm-12.0mm | 1.0m-12m |
| 12" | 323.8mm | 6.0mm-15.0mm | 1.0m-12m |
| 14" | 355.6mm | 8.0mm-15.0mm | 1.0m-12m |
| 16" | 406.4mm | 8.0mm-20.0mm | 1.0m-12m |
